PowerShield PSDR800 Defender Rackmount 800VA/480W

PowerShield PSDR800 Defender Rackmount 800VA/480W

SKU: PSDR800

Barcode: 9346909001030

$490.00
$490.00
Sale Sold out
Shipping calculated at checkout.
This UPS 800VA Defender Rack Mount expands the successful Defender Range by building the popular features into a Rack Mount UPS. At 230mm deep, this is the perfect UPS for shallow, wall mounted Comms cabinets. This versatile UPS uses Automatic Voltage Regulation (AVR) to minimise the effects of fluctuations in input voltage, protecting

your valuable equipment from power line disturbances whilst also incorporating the best surge protection in its class.
  • Surge Protection
  • Informative LCD display
  • Inbuilt Battery Management (HID)
  • The 230mm depth is the shallowest rackmountable solution in the market
  • Can be used standing up
  • Conformal Coating Available as a separate purchase
  • For Technical Help please contact PowerShield on 1300 305 393

Technical Details

Model Number PSDR800
Capacity VA 480W/800VA
Topology Line-interactive
Sine Wave Simulated Sinewave
Form Factor Rackmount
Active Cooling No
SNMP Compatible Yes
Hard-Line No
Hot Swappable Batteries Yes
Australian Outlets - Surge Protection Single Phase
Expandable Batteries Yes
IEC 13 Count 2
Australian Outlets - UPS 6
IEC 19 Count 0
Voltage Range 177-290Vac
Voltage 240Vac
Frequency Range 50Hz or 60Hz Ā±1Hz
Output Voltage 240Vac
Battery Type 12V 9AH (x1)
Phase Count Single Phase
Surge Protection 312 Joules / 6500Amps
Interface USB as standard, Intelligent slot for PSSNMP
Software Power Shield Netguard
LCD Alarm AC Mode, Battery Mode, Low Battery, Fault, Overload
Audible Alarm Batt. Mode, low battery, overload, fault, etc.
Operating Temperature Range 0-40 C
Noise Level Less than 40dB (no fan)
Dimensions 230mm x 438mm x 86mm
Weight 7.7kg
Warranty 2 Years
Warranty 2 Year ARW
